ĦConnector

Description

Our ĦConnector is a rugged and waterproof autoconnecting mesh networking radio device built for high-performance communication in extreme environments. It combines advanced RF capabilities with modular components, making it ideal for building our decentralized off-grid ĦMeshnet.

Key Features:

- Dual AT86RF215 Transceivers: Enables long-range, reliable sub-GHz communication, supporting high data throughput and robustness in challenging conditions.

- Optional Spartan7 FPGA for MIMO: Provides enhanced signal processing and multi-input/multi-output capabilities, optimizing performance in complex networks.

- Raspberry Pi CM4 Module: Powers the device with flexible processing and storage options, enabling versatile software integration and custom applications.

- User-Replaceable 2S 5900mAh Battery: Ensures extended operational times, while the battery remains protected inside the device's IP67-rated toughened case, with access for maintenance purposes.

- Rugged, IP67-Rated Construction: Designed for harsh environments, the device is fully dustproof and waterproof, able to withstand immersion at 1 meter, making it suitable for outdoor use.

- Expandable Display Option: Can be upgraded with a high-brightness, touch-capable screen for enhanced user interface, transforming it into a powerful smartphone or control terminal.

Technical Specifications

Hardware:

- 2x 868 MHz with compliant CE max. power output
- 2x 2.4 GHz with compliant CE max. power output
- U.fl connectors
- Raspberry Pi Compute Module 4 1.5 GHz
- Optional Bluetooth module
- Optional WiFi module
- Optional Spartan 7 FPGA module allowing MIMO algorithms
- MicroSD slot
- Optional Ethernet port module
- Optional 2S Li Ion battery 5900 mAh and BMS
- Optional speaker, microphone, push to talk button modules to use as walkie talkie without a smartphone
- 2x USB-C power delivery ports (power and data)
- On/off physical switch
- 2x LED indicators

The world's most powerful radio meshnet device: our outstanding military-grade dual-band radio module has approximately 10x more bandwidth and range than LoRa and, thanks to our ĦMESH-OS firmware, it can automatically connect to other modules in the vicinity and on the Internet to form the ĦMeshnet. This device from our partner Beechat Network Systems is a true gamechanger and the heart of our radio meshnet technology. (Available for pre-order here!)

Price: 1,199.- USDC

Attention!
Because of limited, but quickly scalable production capacities we can now only take pre-orders to calculate delivery time. You can signal your interest in buying via E-Mail at pre-order@hydramesh.net. Within the next few weeks we will automatically inform you about the launch of our ĦShop in ĦWallet, where you can place your binding order then!
